Pigmento naranja 43-Corimax Orange GR

Technical parameters of Pigment orange 43

Índice de color No.Pigmento naranja 43
Nombre del productoCorimax Orange GR
Categoria de productoPigmento orgánico
Solidez a la luz (recubrimiento)7
Resistencia al calor (revestimiento)200
Solidez a la luz (plástico)7-8
Resistencia al calor (plástico)280
Color
Pigmento-naranja-43-Color
Distribución de hue

Solicitud:
Recomendado para pinturas automotrices, pinturas industriales, recubrimientos en polvo, pastas de impresión, PVC, caucho, PS, PP, PE, PU, tintas a base de agua, tintas solventes, tintas UV.
Sugerido para recubrimientos arquitectónicos, recubrimientos de bobinas, tintas offset.

TDS(Pigment-orange-43)

Estructura molecular:

Physical and chemical properties:

Solubility: Insoluble in acetone, alcohol, chloroform and toluene, slightly soluble in o-chlorophenol and pyridine; dark red light yellow in concentrated sulfuric acid; olive color (red fluorescence) in alkaline insurance powder, red light in case of acid brown.
Hue or light: orange, red light orange.
Relative density: 1.49-1.87
Bulk density / (lb / gal): 12.4-15.6
Melting point / ℃: 460
Average particle size / μm: 0.07
Particle shape: rod-shaped body
Specific surface area / (m2 / g): 46 (GR)
pH value / (10% slurry): 7
Oil absorption / (g / 100g): 96
Poder de cobertura: tipo transparente

Uso del producto:

The molecular structure of the pigment is trans isomer, giving red light orange. Hostaperm Orange GR has a specific surface area of 46 m2 / g. Light and weather fastness grade 7-8. Used for the coloring of acrylonitrile (PAN) puree (cloth, canvas, and tent), transparent polystyrene coloring, soluble in thermoplastic polyester to give a yellow color; metallic luster in paint with metallic aluminum paste; acid / alkali resistance Excellent, also suitable for outdoor latex paint coatings.

Synthesis principle:

Condensation reaction of 1,4,5,8-naphthalenetetracarboxylic acid with o-phenylenediamine at 120 ° C in glacial acetic acid medium to generate cis (blue-red) and trans (yellow-red) The mixture was separated by means of different solubility in potassium hydroxide-ethanol solution, heated at 70 ° C for 1H, the trans isomer was precipitated, filtered, and the crude pigment was hydrolyzed to prepare CI Pigment Orange 43 by pigmentation treatment.
